LM2956S buck-boost power supply module

With a buck-boost module the input voltage can be lower than the output voltage! Put 5V in and get 12V out!

Input 3-40VDC

Output 1.5-35VDC

Maximum output current is 3A however extra cooling may be required over 1A.

Easily adjustable output voltage using the onboard potentiometer. Note the module is supplied set at the maximum output voltage and it will take 15-20 turns anticlockwise before the voltage will start to reduce.

Module size 45x20x14mm
